DS-(M)

發布日期 : 2019-06-23 Print

橋式稱重傳感器采用獨特的橋式結構,傳力組件采用壓頭,鋼球結構,可自動復位和調心,傳感器抗側向力和抗沖擊性能好。經過良好的防潮密封,適應惡劣工作環境。安裝方便.互換性好,可用于制造各種電子汽車衡.軌道衡.料斗稱及各種專用衡器。

Unique bridge structure, cup and steel ball mounted, self-resetting and centering, good side force, resistance and shock resistance, moistureproof sealed, ideal for hostile environment ,simple to install, easy to use, good interchangeability, suitable for electronic truck scale, railroad scale, hopper scale and various special scales.

術參數Technical Parameter
額定載荷Rated Load 10t,15t,20t,25t,30t,40t
靈敏度Sensitivity 2.0000±0.002mV/V
綜合誤差Total Error ±0.02%F.S
蠕變Creep(30minutes) ±0.02%F.S
推薦工作電壓Recommended Excitation Voltage 5V~18V(AC or DC)
最大工作電壓Maximum Excitation Voltage 24V(AC or DC)
零點平衡Zero Balance ±1%F.S
輸入阻抗Input Impedance 775±10Ω
輸出阻抗Output Impedance 700±5Ω
絕緣阻抗Insulation Impedance ≥5000MΩ
安全過載率Safe Overload 150%F.S
極限過載率Ultimate Overload 200%F.S
工作溫度范圍Operating Temperature Range (-30~+70)℃
溫度補償范圍Compensated Temperature Range (-20~+60)℃
輸出溫度影響Temperature Effect On Load ±0.02%F.S/10℃
零點溫度影響Temperature Effect On Zero ±0.02%F.S/10℃
材質Construction 合金鋼Alloy Steel
防護等級Protection Class IP67 &IP68
引用標準Citation GB/T7551-2008/OIML R60
接線方式Mode of Connection 輸入+:紅 Input+:Red
輸入-:黑 Input-:Black
輸出+:綠 Output+:Green
輸出-:白 Output-:White
